1000mm Double Layer Film Extruder

1000mm Double Layer Film Extruder

1000mm Double Layer Film Extruder
JDCPE-65/50

Our 1000mm double layer film extruder is applicable for producing LDPE or LLDPE stretch film for builidng materials and hardware parts packaging. This is the latest multi-function film extruder. This machine adopts double screws. By feeding different types of raw materials to the two hoppers, we can produce stretch films with one side adhesive the other side normal.

Features of 1000mm Double Layer Film Extruder:
1. Nitrogen treated 38CRMOALA alloy is adopted to make screws and cylinders of our film extruders, thus ensuring a capacity of anti-corrosion and long service time, etc.
2. Cycle water cooling device guarantees the best transparency of produced stretch films.
3. Auto change-over and auto cutting devices are applied in the rewinding part.

Technical Parameters of JDCPE-65/50 1000mm Double Layer Film Extruder:

Screw diameter φ65mm 50mm
L/D 30: 1
Finished film width 1000mm
Finished film thickness 0.01-0.03mm
Max. extrusion output 50kg/h
Main motor power 22kw and 11kw
Power supply 380/3/4/50 (Volt/Ph/Line/Hz)
Notes: water, gas, electricity supply for our equipment should be offered by users.

Jianda Machinery Company is an experienced double layer film extruder manufacturer and supplier in China which was built in 1983. Our products have obtained CE certification and have been exported to Iran, Kuwait, Saudi Arabia, Russia, Spain, Italy, Libya, Tunisia, Colombia, Venezuela and other countries. Besides double layer film extruders, we also provide stretch film extruders, film grinders, film casting extruders and other plastic film extruders. If you are interested in our plastic-processing machines, please contact us. Thank you!
